HGH15CA Linear Guide Block

Get a Price/Quote

MOQ : 100 Pieces

HGH15CA Linear Guide Block Specification

Lubrication Type
Grease

Cage Material
Stainless Steel

Thickness
16 mm

Retainer
Standard

Inside Diameter
15 mm

Precision Rating
C5 / C7

Usage
Industrial

Bearing Type
Linear Bearing

Material
Stainless Steel

Size
Standard

Structure
Linear guide block

Seals Type
Double Sealed

Product Type
Linear Guide Block

Number Of Rows
4

Color
Silver

Bore Size
15 mm

Outside Diameter
Standard

Limiting Speed
Up to 120 m/min

Load Capacity
High

Static Load
13.38 kN

Guide Width
15 mm

Model
HGH15CA

Carriage Height
24 mm

Dynamic Load
11.4 kN

Interchangeable
Yes

Mounting Type
Bolt-on

Carriage Length
57.9 mm

Application
CNC Machines, Industrial Automation, Robotics, Precision Equipment

Operating Temperature Range
-20°C to 80°C

Corrosion Resistant
Yes

HGH15CA Linear Guide Block Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
100 Pieces Per Week

Delivery Time
7 Days

About HGH15CA Linear Guide Block

Linear guidesjust two words but they include a wide range of linear motion bearing variations that are utilized across various industries to facilitate straight-line motion. The development of modern linear bearings dates back to the 1950s. Since then, manufacturers explored the opportunities with linear bearings and they developed numerous designs. The primary purpose of a linear guide is to provide support for loads with minimum friction while enabling linear or straight motion.

Advanced Durability and Precision

Manufactured from high-grade stainless steel, the HGH15CA Linear Guide Block combines corrosion resistance with a sturdy construction. With double sealing and precision rating options (C5/C7), it guarantees smooth linear motion and longevity in challenging industrial setups. The guide block's robust load capacity supports high-stress applications including CNC machinery, robotics, and automation systems.

Versatile Application in Industrial Automation

The HGH15CA Linear Guide Block is versatile, suitable for various sectors-from precision equipment and CNC operations to robotics. Its high load capacity, standardized size, and interchangeable design make integration seamless for Indian manufacturers, dealers, and automation specialists seeking consistent and reliable motion solutions.

FAQ's of HGH15CA Linear Guide Block:

Q: How is the HGH15CA Linear Guide Block best installed in CNC machines or automation equipment?

A: The HGH15CA employs a bolt-on mounting system, ensuring secure and straightforward installation onto your machine's compatible guide rail. This ease of mounting supports quick integration into CNC machines, automation systems, or robotic platforms without complex adjustments.

Q: What benefits does the double-sealed design offer for industrial use?

A: The double-sealed structure shields the linear guide block from contaminants like dust, coolant, and debris, greatly extending component life and sustaining smooth, precise motion even in harsh or demanding industrial environments.

Q: When should the HGH15CA be selected over other linear guide block models?

A: Choose the HGH15CA when high load capacity, corrosion resistance, and precision are critical-such as in CNC machining centers, robotics, and high-speed automation. Its stainless steel build and versatile precision ratings (C5/C7) make it reliable for both heavy-duty and precision-focused applications.

Q: Where can the HGH15CA Linear Guide Block be sourced in India?

A: This model is available through a wide network of Indian dealers, distributors, fabricators, manufacturers, exporters, and retailers. Whether you're a supplier or end-user, sourcing from local wholesalers or traders is straightforward across industrial marketplaces nationwide.

Q: What is the operating temperature range and why is it advantageous?

A: The HGH15CA can withstand temperatures between -20C and 80C. This wide range ensures consistent performance in varied industrial environments, from cold storage automation to high-temperature manufacturing floors.

Q: How does the interchangeable design enhance maintenance and replacement?

A: Interchangeability allows for easy replacement and upgrade of the linear guide block without extensive machine modifications. This minimizes downtime and maintenance costs, making machine servicing more efficient.

Q: What makes the HGH15CA suitable for high-speed, high-precision processes?

A: Its precision ratings (C5/C7), high limiting speed (up to 120 m/min), and stable four-row construction deliver reliable accuracy and smooth linear movement. Combined with grease lubrication, these features cater perfectly to high-speed, precision-driven industrial operations.
