TSC SP-22FL BALL TRANSFER UNIT

Price 300.0 INR/ PIECE

Get a Price/Quote

MOQ : 1 PIECE

TSC SP-22FL BALL TRANSFER UNIT Specification

Inside Diameter
22 mm (main ball diameter)

Lubrication Type
Grease

Cage Material
Steel

Retainer
Steel

Precision Rating
Standard

Thickness
20 mm (overall height)

Bearing Type
Ball Transfer

Material
Carbon Steel

Structure
Ball Transfer Unit

Seals Type
Dust Proof

Number Of Rows
Single

Bore Size
22 mm (main ball diameter)

Outside Diameter
35 mm (flange diameter)

Load Capacity
30 kg

Weight
approx. 80g

Mounting Type
Top Flange Mounted

Flange Diameter
35 mm

Mounting Hole Diameter
4.5 mm each

Mounting Holes
3

Main Ball Material
Steel (Hardened)

Finish
Zinc Plated

Operating Temperature Range
-20°C to +80°C

Application
Conveyor, Material Handling, Transfer Tables, and Assembly Lines

Housing Material
Steel

About TSC SP-22FL BALL TRANSFER UNIT

A Ball Transfer Unit (BTU) is a mechanical device allowing omnidirectional movement of loads via a spherical ball.

Key Features

- Spherical Ball: Main rolling element for multidirectional movement.

- Housing: Contains and supports the ball.

- Load Capacity: Varies by design, size.

- Omnidirectional: Facilitates movement in any horizontal direction.

- Low Friction: Enables easy load shifting.

Components

- Top Ball: Exposed spherical ball for contact with load.

- Support Balls: Smaller balls supporting the top ball.

- Housing/Body: Structural containment.

- Mounting: Often flange or base mounted. Applications

- Conveyor Systems: For diverting, sorting loads.

- Material Handling: Omnidirectional load movement.

- Transfer Tables: Facilitating load positioning.

- Packaging Machinery: Item handling.

- Work Positioning: In manufacturing, assembly.

Advantages

- Omnidirectional Movement: Flexibility in load handling.

- Smooth Transfer: Low friction aids movement.

- Space Efficiency: Compact designs available. Types

- Heavy-Duty BTUs: For industrial loads.

- Light-Duty: For lighter applications.

- Corrosion-Resistant: For harsh environments.

Considerations

- Load Rating: Match to application loads.

- Ball Material: Steel, stainless for durability.

- Environmental Factors: Protection from debris.

- Maintenance: Periodic checks for wear, lubrication.

Industries

- Logistics: Sorting, transfer systems.

- Manufacturing: Workpiece handling.

- Automotive: Component handling.

- Aerospace: Parts positioning.

Reliable Material Transfer Solution

Designed with precision and durability in mind, the TSC SP-22FL Ball Transfer Unit excels in conveyor and assembly applications. Its steel construction and zinc-plated finish ensure longevity and resistance to wear, even in demanding environments. The dust-proof seal helps maintain performance by keeping contaminants away from internal components.

Easy Installation and Versatile Use

With a user-friendly top flange mount featuring 3 mounting holes (4.5 mm diameter each), installation is swift and secure. Its compact 35 mm flange effortlessly integrates into existing equipment or new project designs, supporting versatile applications across material handling, transfer tables, and production lines.

FAQs of TSC SP-22FL BALL TRANSFER UNIT:

Q: How is the TSC SP-22FL Ball Transfer Unit installed?

A: The unit features a top flange with three mounting holes of 4.5 mm diameter, allowing it to be easily secured using appropriate screws or bolts onto your conveyor or assembly table.

Q: What applications are best suited for the SP-22FL Ball Transfer Unit?

A: This unit is ideal for conveyor systems, transfer tables, assembly lines, and other material handling setups where items need smooth omnidirectional movement with minimal effort.

Q: When is it recommended to use a ball transfer unit with a dust-proof seal?

A: A dust-proof seal is recommended when operating in environments susceptible to dust and debris, ensuring the ball mechanism functions smoothly and prolonging its service life.

Q: Where can I source the TSC SP-22FL Ball Transfer Unit in India?

A: This product is available through authorized dealers, distributors, exporters, manufacturers, suppliers, traders, retailers, and wholesalers across India.

Q: What benefits does the hardened steel main ball provide?

A: The hardened steel main ball offers superior wear resistance and durability, enabling reliable load transport up to 30 kg without deformation or significant wear.

Q: How does the zinc-plated finish benefit the ball transfer unit?

A: The zinc-plated finish provides excellent corrosion resistance, making the unit suitable for use in environments where exposure to moisture or chemicals may occur.
