Linear Guides

Get a Price/Quote

MOQ : 100 Pieces

Linear Guides Specification

Precision Rating
High Precision

Retainer
Built-in Retainer

Inside Diameter
16 mm

Cage Material
Polymer

Thickness
Standard

Lubrication Type
Oil Lubrication

Usage
Industrial

Bearing Type
Linear Motion Bearing

Material
Stainless Steel

Size
Standard

Structure
Slide Rail

Seals Type
Contact Seal

Product Type
Linear Guides

Number Of Rows
Double Row

Bore Size
16 mm

Color
Silver

Outside Diameter
22 mm

Limiting Speed
Up to 15 m/s

Load Capacity
Medium to High

Operating Temperature Range
-20°C to 80°C

Application
Automated Machinery, CNC Equipment

Corrosion Resistance
Yes

Guide Length
Customizable

Mounting Type
Bolt Mount

Linear Guides Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
100 Pieces Per Week

Delivery Time
7 Days

About Linear Guides

Purchase the famed Linear Guides with Bolt Mount, offering unparalleled performance in automation and CNC applications. Crafted from radiant stainless steel, these guides exhibit robust corrosion resistance, flawless operation between -20C and 80C, and a high precision rating. Guide length is entirely customizable, catering to your project's requirements. The medium to high load capacity ensures reliability for demanding industrial settings, while the double row structure with built-in retainer and oil lubrication maximizes efficiency. Get a radiant deal from India's leading dealer, distributor, exporter, manufacturer, and supplier network.

Wider Industrial Uses of Linear Guides

Linear Guides are utilized beyond automated machinery and CNC equipment; they thrive in robotics, packaging lines, material handling systems, and precise laboratory automation. These guides serve indispensable roles in electronics assembly, textile machinery, and printing presses, thanks to their high precision and robustness. Their application places extend across factories, research laboratories, and sophisticated engineering setups, covering industries such as automotive, food processing, and pharmaceutical production where repeatable accuracy and durability are essential.

Logistics, Payment Terms, and Packaging Details

Our Linear Guides are available with flexible payment terms designed for your convenience and security. Sale price depends on customization and quantity, providing value for volume orders. Products are carefully packaged in secure, industry-grade packaging to ensure safe transit. Dispatched quickly from major Indian FOB ports, our logistics network guarantees timely delivery across local and international markets. Every shipment is tracked for prompt and responsible service, giving you peace of mind throughout the purchasing process.

FAQ's of Linear Guides:

Q: How can the guide length be customized for specific applications?

A: Guide length can be tailored during the manufacturing process according to your specified dimensions, ensuring exact compatibility with your automated machinery or CNC equipment. Discuss your requirements with our design team to obtain the optimal solution.

Q: What is the benefit of using stainless steel with a contact seal in these Linear Guides?

A: Stainless steel construction provides long-lasting corrosion resistance, while the contact seal helps keep contaminants out and lubrication in, translating to extended operational life and reduced maintenance.

Q: Where are these Linear Guides commonly installed?

A: These guides are typically installed in industrial settings such as manufacturing plants, automated assembly lines, CNC machining centers, robotics workstations, and other locations that demand high-precision linear motion solutions.

Q: What is the process for purchasing and receiving these Linear Guides from India?

A: Simply contact our sales team or authorized dealer network to place your order. After confirming specifications and payment terms, your guides are packaged securely, dispatched from a major FOB port, and delivered to your international or local address with efficient logistics support.

Q: How does the built-in retainer improve usage and reliability?

A: The built-in retainer maintains precisely spaced rolling elements, ensuring consistently smooth movement, minimizing internal friction, and enhancing the guide's longevity and reliability in demanding operations.
