CF12UU Cam Follower Bearings

Get a Price/Quote

MOQ : 100 Pieces

CF12UU Cam Follower Bearings Specification

Weight
120 g

Thickness
15 mm

Usage
Industrial

Material
Stainless Steel

Roller Bearing Type
Stud Type Cam Follower

Product Type
Cam Follower Bearings

Structure
Separable

Seals Type
Double Sealed

Color
Silver

Number Of Rows
Single Row

Bore Size
12 mm

Outside Diameter
32 mm

Limiting Speed
9000 RPM

Load Capacity
Up to 4500 N

Inner Diameter
12 mm

ISO Standard
ISO 9001 Certified

Cage Material
Nylon

Stud Length
24 mm

Corrosion Resistance
Yes

Thread Size
M12 x 1.5

Operating Temperature Range
-20°C to +120°C

Type
CF12UU

CF12UU Cam Follower Bearings Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
100 Pieces Per Week

Delivery Time
7 Days

About CF12UU Cam Follower Bearings

Linear bearings are mechanical devices that enable linear motion with minimal friction along a straight path. These components, also known as linear bushings, play a crucial role in guiding objects along linear shafts or linear rails, facilitating precise movement in a controlled manner.

High-Performance Design for Industrial Use

CF12UU Cam Follower Bearings are engineered to meet rigorous industrial requirements. The use of stainless steel provides excellent corrosion resistance, while the double-sealed structure and nylon cage ensure long-lasting protection and smooth operation. Certified to ISO 9001 standards, these bearings guarantee reliable quality and performance for varied industrial purposes across India.

Versatile Application and Easy Installation

With a stud length of 24 mm and an M12 x 1.5 thread, the CF12UU is compatible with a wide range of machinery. Its separable, single row design facilitates straightforward installation and maintenance, making it suitable for dealers, distributors, producers, and more. The high limiting speed and robust load capacity ensure efficiency in dynamic environments.

FAQ's of CF12UU Cam Follower Bearings:

Q: How should the CF12UU Cam Follower Bearing be installed in industrial equipment?

A: The CF12UU Cam Follower Bearing is designed for ease of installation, featuring a stud type with M12 x 1.5 threading and a 24 mm stud length. Simply screw the bearing into the mounting hole that matches the thread specifications, ensuring the surface is clean and free of debris. Secure with the appropriate nut or fastener to achieve stable performance.

Q: What advantages does the nylon cage and double-sealed design offer?

A: The nylon cage helps to reduce friction and wear, while also allowing smoother movement of internal components. The double-sealed design enhances protection against contaminants such as dust and moisture, significantly extending the bearing's operational life in harsh industrial environments.

Q: When is it recommended to use the CF12UU cam follower in industrial operations?

A: This bearing is especially suitable when you require high durability, corrosion resistance, and operation within temperatures from -20C to +120C. It performs well in high-speed applications up to 9000 RPM and carries loads up to 4500 N, making it ideal for automated machinery, conveyors, and other dynamic systems.

Q: Where are these bearings typically supplied or distributed within India?

A: CF12UU Cam Follower Bearings are widely available across India through a broad network of dealers, distributors, retailers, and wholesalers. They are also supplied directly by fabricators, manufacturers, exporters, and traders serving a variety of industrial sectors.

Q: What are the benefits of choosing an ISO 9001 certified cam follower bearing like the CF12UU?

A: Selecting an ISO 9001 certified bearing ensures you receive a product manufactured to rigorous quality standards. This guarantees consistent performance, reliable operation, and traceable production processes, reducing the risk of equipment downtime and maintenance costs.

Q: How does the corrosion-resistant, stainless steel structure enhance the bearing's suitability for industrial use?

A: The stainless steel construction offers superior protection against corrosion, making these bearings ideal for environments exposed to moisture or chemicals. This durability translates into reduced maintenance, a longer service life, and lower replacement frequency, even in challenging conditions.
